Digital Multimeter Function Generator Victor Model 2006A (60MHz two-chanel)
Product information
The two-channel function/arbitrary waveform generator is equipped with direct digital synthesis (DDS) technology which enables output signals to be stable and accurate.
Key Features:
- 3.5-inch 480×320TFT LCD with clear graphic interface
- Chinese / English menu available
- Press key for help and information
- File management supporting USB flash disk and local storage
- Two-channel output with the highest output frequency is “15M type” Model is 15MHz, Victor 2003A is 25MHz, Victor 2004A is 40MHz, Victor 2006A is 60MHz.
- Sampling rate: 200MSa/S, vertical resolution: 13 bit and storage depth: 8k
- 5 basic waveforms and 32 arbitrary waveforms in-built
- Pulse wave output set in edge
- Time Internal/external AM, FM, PM, ASK, FSK and PSK modulation function
- Output of linear/logarithmic frequency sweep and burst waveform
- Frequency meter of high precision of 100MHz and 32-bit counter
- With RS232 interface, USB Device, USB Host interface supporting USB flash disk storage (USB Host Optional)
- Multi-functional arbitrary waveform editing software equipped
Spesifikasi Produk
- Frequency Characteristics
- MODEL : 1μHz ~ 60MHz
- Sine : 1μHz ~ 15MHz
- Triangle : 1μHz ~ 15MHz
- Pulse : 100μHz ~ 6MHz
- Arbitrary : 1μHz ~ 6MHz
- Noise （-3dB : 7MHz Bandwidth
- Frequency Resolution : 1μHz
- Frequency Accuracy : ±5ppm
- Frequency Stability : ±1ppm/3hour
